NA-11242-CDC

Representative photo(s): actual product specifications may vary from that shown in the photo

MAC Two-Lumen Central Venous Access for use with 7.5 - 8 Fr. Catheters

MULTI-LUMEN/PSI KIT

SKU / Article #: NA-11242-CDC

Highlights

  • Sharps Safety

Contraindications & Considerations

  • Not made with natural rubber latex.
  • Includes Lidocaine
  • ┬▒Precaution: Contains Phthalate: DEHP

Sales Quantity/Case: 5

MAC Two-Lumen Central Venous Access for use with 7.5 - 8 Fr. Catheters
SKU / Article #: NA-11242-CDC
Quantity Component Description
1 Two-Lumen Central Venous Access Device: 115 mm Radiopaque Polyurethane with 9 Fr. Distal Lumen, Integral Hemostasis Valve, Extension Line Clamps
1 Spring-Wire Guide, Marked: .035" (0.89 mm) dia. x 17-3/4" (45 cm) (Straight Soft Tip on One End - "J" Tip on Other) with Arrow Advancer
1 Catheter: 18 Ga. x 2-1/2" (6.35 cm) Radiopaque over 20 Ga. RW Introducer Needle
1 Injection Needle: SafetyGlide1 25 Ga. x 1" (2.54 cm)
1 Blunt Fill Needle: 18 Ga. x 1-1/2" (3.81 cm)
1 Pressure Transduction Probe
1 Introducer Needle: Echogenic 18 Ga. x 2-1/2" (6.35 cm) XTW and 5 mL Arrow® Raulerson Spring-Wire Introduction Syringe
1 Injection Needle: SafetyGlide1 22 Ga. x 1-1/2" (3.81 cm) and 5 mL Luer-Slip Syringe
1 Syringe: 3 mL Luer-Lock
1 Tissue Dilator
1 5 mL 1% Lidocaine HCl Solution and Alcohol Prep
1 3 mL Applicator 2% CHG and 70% IPA ChloraPrep®2 One-Step Solution with Hi-Lite Orange Tint
1 Obturator: 8 Fr.
1 Cath-Gard® Catheter Contamination Shield: 80 cm with TwistLock Adapter
1 Dust Cap: Vented
2 Dust Cap: Non-Vented
1 SharpsAway® Disposal Cup
1 SharpsAway® II Locking Disposal Cup
1 Drape: 41" x 55" with 4" fenestration
1 Needle Holder
1 Safety Scalpel: #11
1 Stopcock: 4-way High-Flow
1 Medication Label: 1% Lidocaine
2 Gauze Pad: 2" x 2" (5 cm x 5 cm)
5 Gauze Pad: 4" x 4" (10 cm x 10 cm)
1 Suture: 3-0 Silk with Curved Needle
1 Tubing┬▒: 20" (50 cm) Extension
1 A trademark of Becton, Dickinson and Company.
2 A registered trademark of CareFusion or one of its subsidiaries.

Documents

  • K 07800 121
  • K 01552 112a
  • K 11142 104a
  • Ic 11242 100b
Scroll to View More
  • K 07800 121
  • K 01552 112a
  • K 11142 104a
Scroll to View More
  • Ic 11242 100b
Scroll to View More
The products in this catalog may not be available in all countries. Please contact your local representative.
Indications, contraindications, warnings and instructions for use can be found in the Product Instructions for Use available under the Documents section on this page, where an IFU is available.
